Technical Parameters:
• Max. Allowable pressure: 25 bar
• Working pressure: 0-8 bar
• Ambient Temp: -10 to 65°C
• Flow Direction: Follows the indicated arrow
• Installation: Mountable in any position; vertical and upright is the optimal orientation.

Available Voltage Options:
AC110V/50Hz, AC120V/60Hz, AC220V/50Hz, AC240V/60Hz, AC230V 50/60Hz, AC36V 50/60Hz, AC24V 50/60Hz, DC24V, DC12V (Tolerance: ±10%).

Since 1993, the production line has expanded to more than 100 series and 10,000 kinds of specifications, widely used in various pipeline automatic control media. Product flow diameters range from DN0.1 to DN150mm, with operating pressures spanning from vacuum up to 1050 bar.

The manufacturing processes are certified under ISO9001 quality management, ISO14000 environmental management, and ISO45000 occupational health and safety systems. Products comply with international standards including European TUV, CE, WRAS, NSF, UL, and China Ex explosion-proof 3C certification.

As a high-tech enterprise and recognized "little giant" entity, it holds more than 50 patents for solenoid valve inventions and utility models. The technical development is supported by professional R&D and Engineering Centers.
